tilt and turn

-

BINQ Tilt and Turn Windows are the highest performing window available. BINQ's proprietary design makes in the best performing (lowest uValue) window manufactured in Australia. With the turn of a handle the window tilts in at the top, promoting passive and secure ventilation, keeping your house fresh but safe also. Turn the handle again and the window turns in at over 90 decgrees, giving you rapid ventilation. Out Tilt Turns feature Australain made double or triple glazed safety glass and high security multipoint locking system providing the ultimate security.

Features

  • German Hardware

  • High Security Locking System (5 points)

  • Double Gaskets

  • 68mm Timber Profiles

  • 28mm Double & Triple Glazing

  • 32mm Double & Triple Glazing (for ultimate performance)

  • Custodial Safety Locks (for multi level buildings)

Size Restrictions

  • Up to 2.7m high

  • Up to 1.4m wide (per sash)

Performance

  • uVal - as low as 1.1

  • SHGC - as low as .258

Options

Technical Designs



TIMBER species

-

Vic Ash

Bushfure Rating: BAL19



Properties

  • Density: 675-770kg/m3 at 12% moisture content; 1.3 to 1.5m3 of seasoned sawn timber per tonne.

  • Strength groups: S4 unseasoned, SD4 seasoned.

  • Stress grades: F7, F8, F11, F14 (unseasoned); F11, F14, F17, F22 (seasoned) when visually stress-graded according to AS 2082—2000: Timber—Hardwood—Visually stress-graded for structural purposes.

  • Joint groups: J3 unseasoned, JD3 seasoned.

  • Shrinkage to 12% MC: E. regnans—13.3% (tangential), 6.6% (radial); E. delegatensis—8.5% (tangential), 5.2% (radial); E. oblique—11.3% (tangential), 5.1% (radial).

  • Unit shrinkage: E. regnans—0.36% (tangential), 0.23% (radial); E. delegatensis—0.35% (tangential), 0.22% (radial). E. oblique—0.36% (tangential), 0.23% (radial). These values apply to timber reconditioned after seasoning.

  • Durability above-ground: Class 3 (life expectancy 7–15 years).

  • Lyctine susceptibility: untreated sapwood of E. delegatensis and E. obliqua is susceptible to lyctid borer attack; untreated sapwood of E. regnans is not susceptible; normally marketed as a mix of the 3 species; therefore, classed as lyctid susceptible.

  • Termite resistance: not resistant.

Blackbutt

Bushfire Rating: BAL29

Properties

  • Air dry density: 930kg/m3 at 12% moisture content; about 1.1m3 of seasoned sawn timber per tonne.

  • Plantation-grown timber: age 4 years—64% mature timber density; age 11–17 years—80 to 88% mature timber density.

  • Strength groups: S2 unseasoned, SD2 seasoned.

  • Stress grades: F11, F14, F17, F22 (unseasoned), F17, F22, F27, F34 (seasoned) when visually stress-graded according to AS 2082—2000: Timber—Hardwood—Visually stress-graded for structural purposes.

  • Joint groups: J2 unseasoned; JD2 seasoned.

  • Shrinkage to 12% MC: 7.3% (tangential), 4.3% (radial).

  • Unit shrinkage: 0.37 % (tangential) 0.26 % (radial)—these values apply to timber reconditioned after seasoning.

  • Durability above-ground: Class 1 (life expectancy more than 40 years).

  • Lyctine susceptibility: sapwood is not susceptible to lyctine borer attack.

  • Termite resistance: resistant.

FINISHES

-

Our Timber products can either be Raw, Primed or Stained. Our Staining material is imported from Germany and specifically designed for Timber Windows and Doors. To ensure that all areas of the timber are coated, all finishing is completed prior to any glass or hardware being fitted.

Finishing consists of a four part process.

Prepping

Each unit is bogged, puttied and sanded to ensure that the finish is soft, smooth and consistent.

Priming

The priming (base coat) of the unit by dipping it into a staining tray, which penetrates the timber and treats for rot an infestation, then the unit is hung to try in a controlled temperature enviroment, which generally takes 24 hours.

Re Prepping

Once the unit is dry, it's lightly sanded to ensure that an even and consistent finish is achieved throughout.

Top Coat

It then progresses into the finishing line and the top coat is applied by a spray gun at approximately 400 microns thick (equivolent to 3 coats of paint). The unit is then placed in the drying room which again is at a controlled temperature enviroment.

  • Raw

  • Primed

  • Blackwood

  • Chocolate Haze

  • Nighthawk

  • Maple

  • Vintage Rose



hardware

-

  • S60

  • Project PCS

  • Project ONO

  • PR22_PVDSG.png

    Edra 02 PVDSG

  • Edra 02 PCS



GLASS

-


Windows with standard glass provide little to no insulation properties, and are the thermal weak point in buildings. In an average home, 40% of heat loss and 87% of heat gain is through inefficient glazing*.

An energy efficient window helps minimise the use of artificial heating and cooling, and makes the most of the natural climate resources. Insulglass IGU units are an essential component to minimise the need for artificial heating and cooling, reducing heat transfer by over 50%.

Utilising energy efficient glass has many benefits:

  • Comfort levels: it will be naturally cooler in summer and warmer in winter, internal drafts and condensation is reduced

  • Energy savings: lowered cost for conditioning spaces with artificial heat and cooling

  • Less greenhouse emissions: with a lower load impact on artificial heating and cooling, there is less energy output and reduced emissions

  • Noise reduction: filters out significantly more noise than standard glass

Insulglass

uVal - as low as 1.89

SHGC - as low as 0.67

Insulglass Plus

uVal - as low as 1.3

SHGC - as low as 0.58

Audiosheild

DB - up to 55
